Benefitting from many years of extensive research by Hitachi, the ZW160-7 is designed to meet the needs of operators and owners perfectly, enabling them to control their safety, comfort and uptime. Its industry-leading cab offers superior visibility so work can be carried out confidently, productively and efficiently in challenging conditions.
ZW160-7
- 123kw Engine Rated Power
- 2.0 - 3.6m3 Bucket Capacity
- 13,020kg Operating Weight
- Engine
- Tires
- Brakes
- Steering System
- Hydraulic System
- Powertrain
- Axle and Final Drive
- Environment
- Service Refill Capacities
- Dimensions And Specifications
- Engine Model: CUMMINS B4.5
- Engine Type: 4-Cycle water-cooled, direct injection
- Aspiration: Turbocharger and intercooled
- No. of cylinders: 4
- Maximum power ISO 14396:123 kW / 165 hp
- Maximum torque, gross:755 Nm at 1 200 min-1 (rpm)
- Bore and stroke: 107 mm X 124 mm
- Piston displacement:4.46 L
- Batteries: 2 x 12 V
- Tire size: 20.5R25 (L3)
- Optional: Refer to standard & optional equipment list
- Service brakes:Inboard mounted fully hydraulic 4 wheel wet disc brakes. Front & rear independent brake circuit, HST (Hydro Static Transmission) system provides additional hydraulic braking capacity.
- Parking brakes:Spring applied, hydraulically released, wet disc type
- Type: Articulated frame steering
- Steering angle: Each direction 40° ; total 80°
- Cylinders: Double-acting piston type
- No. x Bore x Stroke:2 x 65 mm x 419 mm
- No. x Bore x Stroke: Arm (2 x 125 mm x 760 mm) Bucket (1 x 150 mm x 495 mm)
- Main pump:Gear type
- Maximum flow: 194 L/min at 2 200 min-1 (rpm)
- Hydraulic cylinders Type: Double acting type
- Transmission: Electrical-controlled 2 motor hydrostatic transmission with summation gear box, Gear box : Fixed gear ratio, powershift countershaft type.
- Travel speed* Forward / Reverse 1st: 13 / 13 km/h (13 / 13 km/h)
- Travel speed* Forward / Reverse 2nd: 13 / 13 km/h (13 / 13 km/h)
- Travel speed* Forward / Reverse 3rd: 20 / 20 km/h (20 / 20 km/h)
- Travel speed* Forward / Reverse 4th: 39 / 39 km/h (39 / 39 km/h)
- Drive system: Four-wheel drive system
- Oscillation angle: Total 20° (+10° ,-10°)
- Engine Emissions:Complies with EU stage V
- Sound level in cab according to ISO 6396: 67 LpA dB(A)
- External sound level according to ISO 6395 and EU Directive 2000/14/EC: 104 LwA dB(A)
- Air Conditioning System:The air conditioning system contains fluorinated greenhouse gases. Refrigerant type: HFC-134a, GWP: 1430, Amount: 0.75±0.05kg, CO2e: 1.07±0.07ton.
- Fuel tank: 205 L
- Engine coolant: 20 L
- Engine oil: 16 L
- Torque converter & transmission: 30 L
- Front axle differential & wheel hubs: 25 L
- Rear axle differential & wheel hubs: 25 L
- Hydraulic oil tank: 80 L
- DEF/AdBlue® tank: 18 L
- Overall length (without bucket) (mm): 6 420 mm (standard arm) 6 905 mm (High-lift arm)
- Overall height up to cab top (mm): 3 280 mm
- Ground clearance (minimum) (mm): 430 mm
- Turning radius (centerline of outside tire) (mm): 5 085 mm
- Turning radius to inside of tires (mm): 2 870
- Height to bucket hinge pin, fully raised (mm): 3 840
- Lift arm clearance at max lift (mm): 3 570 mm (standard arm) 4 055 mm ( High-lift arm)
- Static tipping load (Straight) (kg): 10 610 kg (Standard arm) 9 780 kg (High-lift arm)
- Breakout force (kN): 105 kN 10 690 kgf (Standard arm) 103 kN 10 490 kgf (High-lift arm)
- Operating weight (kg): 12 910 kg (standard arm) 13 080 kg (High-lift arm)
